Stainless Steel High Precision Rotary Drum Filter

Brief Introduction：
Stainless Steel High Precision Rotary Drum Filter is one new type of filter with multi-function, it includes filter housing and filter. It is widely used in many industries, such as drinking water pretreatment, cooling water system, drainage water quality improvement, precision filtration device before membrane treatment section, water purification of fishery / aquaculture, etc.

Applications:
It is suitable for municipal sewage, tap water, industrial waste water, fishery, aquaculture, food, beverage, animal husbandry, chemical industry, machinery manufacturing, metal processing, petroleum, printing and dyeing, washing, papermaking and other industries.

Structure composition:
1. Filter Body 2.Key filtration system-mesh 3. Bash wash system 4.Control System
Filter body:including housing shell, central water inlet pipe, rotating cyclinder, linkage gear, rotaring bearing, seal etc. Collection and drainage tank at top of rotating cycliner are all made of SS304
Back wash system:include backwash water pump, flushing water pipe, nozzle system, waste collection tank, sewage pipe.
Pecision filter mesh:Filter mesh precision:10~100micron。 Material：SS316L
control system:The shell of the control cabinet is made of cold-rolled plate, which shows that it has been treated with polyester powder coating, and the protection grade is IP65. PLC control system with on-off button, automatic-manual switch, urgent stop buttons and fault alarm system.
slowdown system:include motor, gear and rotating cyclinder support wheel. Motor：380V/50HZ/3phase
Water Treated Flow:50-500m3/h or other can be custom made as per requirement.

Main parameter:

Parameter	mesh drum diameter(mm)	Treated Water Flow (m3/h)	Size(mm)	Power (KW)	Bashwash Water
Model	mesh drum diameter(mm)	Treated Water Flow (m3/h)	Size(mm)	Power (KW)	water flow (m3/h)	water pressure (Mpa)
SIIC-DF50	600	50	24501000942	0.37	1.5-2.5	>0.245
SIIC-DF100	900	100	325013001218	0.75	2.5-3	>0.245
SIIC-DF150	1050	150	346014001236	1.1	3-4	>0.245
SIIC-DF200	1200	200	346015001483	1.5	4-5	>0.245
SIIC-DF300	1350	300	365017001687	1.5	5-6	>0.245
SIIC-DF400	1500	400	370018001833	2.2	5-6	>0.245
SIIC-DF500	1600	500	386018201920	2.2	6-7	>0.245
