Nomex/Aramid Dust Collector Filter Bags/Sleeves
Data:
Material: aramid felt
Weight: 350-650gsm
Working temperature: 203-240 degree centigrade
Basic finish treatments: singed, calendered, heat set
Available functional treatments: water and oil repellent, anti-static, PTFE lamination or membrane.
Size:
Diameter: normally 4.375”(111.125mm), 4.5”(114.3mm), 4.625”(117.475mm), 4.75”(120.65mm), 4.875”(123.825mm), 5”(127mm), 5.125”(130.175mm), 5.25”(133.35mm), 5.625”(142.875mm), 5.85”(148.59mm), 6”(152.4mm), 6.1”(154.94mm), 6.25”(158.75mm), 8.5”(215.9mm) and others be custom made as per your requirement.
Length: normally 121” (3073.4mm), 145” (3683mm), any other lengths are available.
Structure:
Bag body: stitched or welded
Bag top/bottom types: beaded snap band top/bottom, raw top, hemmed top, corded/rubber O-ring top, thick gasket top, disc bottom, flat sewn bottom, bottom with reinforcement(cuff bottom)
Bag shapes: standard round tube, envelope or other special shapes can be custom-made as per customers’ requirements.
Top with Wheelabrator Style(No Beads) raw top
Features:
-normal temperature resistant
-Made of 100% aramid fiber
-Direct manufacturer
Applications:
Nomex/Aramid dust collector filter bags sleeves are widely used in industries of cement, steel making and casting, carbon black, boilers, asphalt and other high temperature dust collection fields.
Nomex/Aramid dust collector filter bags sleeves applications examples:
Carbon black collection filter bags/sleeves
Filter bags/sleeves used in asphalt concrete mixer/asphalt mill/asphalt plant
Filter bags/sleeves used in cement plant/mills
