Extended Life Range POXL/PEXL Filter Bags

Extended Life Range POXL/PEXL Filter Bags

Item No.: SIIC-BPOXL, BPEXL
SIIC extended life range POXL/PEXL, alternative filter bag of EATON DURAGAF filter bags, are with equal filtration performance with lifetimes 2-5 times longer than ordinary felt media. Email:service@filterworkshop.com
INQUIRY
Description

Extended life range POXL/PEXL filter bags/Alternative filter bag of EATON DURAGAF filter bags

Data:

Be one alternative filter bag of EATON DURAGAF filter bags.

Sizes:1# 7*17”(180*430mm), 2# 7*32”(180*810mm), other sizes can be custom made
Size 1#: 7”*32”

Size 2#: 7”*17”

Micron rating: 1, 5, 10, 25, 50micron (um)

Features:

(1) High Performance

SIIC Extended life range POXL-PEXL filter bags represent the state-of-the-art in needled felt bag filter media. Their unique structure delivers equal filtration performance with lifetimes 2-5 times longer than ordinary felt media. The result is reduced operating costs due to lower bag consumption, downtime, change-out labor, storage and disposal.

(2) Last longer

SIIC Extended life range filter bags are available in two extended life materials: polypropylene (code POXL) or polyester (code PEXL). These two materials utilize a fiber blend with a finer fiber diameter and a higher weight than ordinary media. The result is a dramatically higher dirt holding capacity at the same efficiency and differential pressure.  Processes run longer and need fewer bag changes with SIIC extended life range POXL-PEXL filter bags.

(3) All-Welded Construction for Superior Performance

All SIIC Extended life range POXL-PEXL filter bags feature 100% welded fabrication. This construction eliminates the bypass which can occur in standard sewn filter bags.

(4) Seal Better in Critical Applications

The unique, pressure-actuated ring actually improves its seal as differential pressure increases.

(5) No Downstream Fiber Contamination

All SIIC Extended life range POXL-PEXL filter bags are manufactured with a proprietary downstream surface treatment to prevent fiber migration. A special finish is obtained by glazing the surface, melting fibers together to form a tight, secure downstream matrix. In addition, the weld seams are heat bonded to eliminate loose fibers which might result during fabrication.

(6) Food and Beverage Applications

SIIC Extended life range filter bags are available in models (POXL, PEXL) which are compliant with FDA and EC requirements for food contact.
